    Degreasing Ceramic Sintering Furnace , High Temperature Sintering Furnace

    Ask Lasest Price
    Brand Name : EasyFashion Industry
    Model Number : GN5518A
    Certification : CE Certificate
    Supply Ability : 10 set per year
    Delivery Time : 120 days
    • Product Details
    • Company Profile

    Degreasing Ceramic Sintering Furnace , High Temperature Sintering Furnace


    For ceramic material Degreasing Vacuum Sintering And De-waxing Furnace Directional Airflow


    Pumping speed (in cold and clean chamber) ≤20 min., pumping from 1.13×105Pa to 5Pa

    Com deviation ≤±0.2%

    Max. testing temperature 1600°C

    Max. working temperature ≤1550°C


    Main Description

    Integrated Vacuum Degreasing and Sintering Furnace integrate the functions of de-waxing, sintering, atmosphere controlling and cooling etc.


    Technical specifications


    Model

    GN5518AGN3312A

    Com deviation

    ≤±0.2%

    Power

    340 kVA200 kVA

    Dimension of usable space

    500×500×1800 mm300×300×1200mm

    Max. load weight

    1500 kg500 kg

    Weight of furnace

    ≈5500 kg≈4000 kg

    Stand area

    ≈5200×6000 mm≈4500×4000mm

    Dimension of furnace

    4500×5400×3500 mm4500×4250×3500 mm

    Max. testing temperature

    1600°C

    Max. working temperature

    ≤1550°C

    Temperature control method

    3 zones

    Temperature uniformity

    ≤±7°C

    (Ceramic ring)


    Pumping speed

    (in cold and clean chamber)

    ≤20 min., pumping from 1.13×105Pa to 5Pa

    Rated voltage

    380 V 50 Hz, three-phase five-wire

    Temperature increasing rate (without loading)

    15°C/min(≤1000℃);

    10°C/min(≥1000℃)

    Ultimate vacuum

    ≤2Pa, tested in cold and clean chamber

    Vacuum Leak rate

    ≤2Pa/h(24 hours average), tested in cold and clean chamber

    Hc deviation

    ≤±0.3KA/M

    Wax collecting rate

    ≥98﹪

    Cooling speed

    (without loading)

    (cooling water ≤30°C)

    From working temp. to 800°C, ≤ 3 h

    From 800°C to opening door, ≤ 6 h

    From working temp. to 800°C, ≤ 2 h

    From 800°C to opening door, ≤ 5 h
