    50L Blending Spray Drying Equipment Z Type With Alcohol Recycling System

    50L Overall Function Z - type Blending Dryer For cemented Carbide Powder


    1. Overview

    The equipment consists of main body, vacuum pump, TCU, and alcohol recycling system..

    The box of the equipment with double-walled water jacket is made of stainless steel. Specially, the inner wall is made of stainless steel with mirror surface.

    There are two Z-type shafts, which are processed from two whole stainless steel forging.


    2. Technical specifications

    Model

    GN050D

    Ultimate vacuum

    -0.06MPa

    Blending power

    1.5kW

    Working frequency

    10~50Hz

    ( Adjustable)

    Power of vacuum pump

    3KW

    Pumping rate

    0.84 m3/min

    Max. capacity

    35L

    Rated voltage

    380 V 50 Hz, three-phase five-wire

    Max. blending weight

    50 kg/run
