Silver Powder Manufacturing Equipment 300Kg With High Pressure Water Atomization

    Buy cheap Silver Powder Manufacturing Equipment 300Kg With High Pressure Water Atomization from wholesalers

    Buy cheap Silver Powder Manufacturing Equipment 300Kg With High Pressure Water Atomization from wholesalers
    • Buy cheap Silver Powder Manufacturing Equipment 300Kg With High Pressure Water Atomization from wholesalers

    Silver Powder Manufacturing Equipment 300Kg With High Pressure Water Atomization

    Ask Lasest Price
    Brand Name : Easyfashion Industry
    Model Number : EFSWH-300
    Certification : CE Certificate
    Payment Terms : T/T, D/A, D/P, Western Union
    Supply Ability : 10 sets per year
    Delivery Time : 120 days
    • Product Details
    • Company Profile

    Silver Powder Manufacturing Equipment 300Kg With High Pressure Water Atomization

    Low Bulk Density Water Atomization Powder Manufacturing Equipment 300Kg For Silver Powder


    Overview

    The process is simple and the technology is easy to master. Our water atomization powder manufacturing equipment produces 10~1,000kg powder per batch. It’s also can produce alloy powders, such as iron-based powder, nickel-based powder, copper-based powder, silver-based powder, etc.. Moreover, customized equipment is also available to cater to customer’s specific requirements on batch capacity and particle size.

    It is a kind of equipment with lower production cost. The water atomization powder manufacturing equipment is a mature technology in powder metallurgy industry. This kind of powder production machine utilizes high-pressure water flow to atomize molten metal into powder particles. It’s highly recommended for production of iron powder, copper powder, stainless steel powder and alloy powder.


    Features

    1. Oxygen content can be reduced by the subsequent reduction process.

    2. The atomized powder by the equipment is irregular with relatively high content of oxygen.

    3. Weoffer the whole water atomizing production line, including water atomization powder manufacturing equipment, reduction furnace, nitrogen circulating system, ball mill machine, sieving machine, mixing machine etc..

    Specifications


    ModelEFSWH-30EFSWH-50EFSWH-100EFSWH-300EFSWH-500EFSWH-1000

    High-pressure water pressure

    (MPa)

    30~120
    High-pressure water flow (L/min)50~800
    Furnace weight (kg)30501003005001000
    Highest melting temperature°C1750
    Melt heating power (kW)50100160300400600
    Temperature measuring methodInfrared thermometer, WRe5.26
    Tundish heating power (kW)20~45
    Power supply3 phases, 380V, 50Hz
    Installed total power (kW)Based on different capacity and configuration
    Cooling water flow (L/min)150300400700
    Cooling water deviceFan cooling tower, water cooling unit, heat exchanger
    Soft water flow (m3/h)6~20
    Control modeIndustrial control computer or PLC
    Operation interfaceTouch-tone or Touch-screen
    Data recording12 data-curve recording, LCD monitoring display

    Appearance size

    (LxWxH) (mm)


    7500x4000x65007500x4200x65008200x5200x65009200x6500x65009500x6500x650010000x7000x6500
