    Pressure Spray Drying Tower cemented carbide drying equipment

    Spray Drying Tower


    1.Overview

    Spray drying tower is mainly used for drying cemented carbide mixture.

    Heating method: N2 heated by electric heated thermal oil

    Nebulization method: Pressure spray nozzle

    Pressure Spray Drying Tower cemented carbide drying equipment

    2.Specifications

    TypeGN300S
    Rated voltage380 V 50 Hz, three-phase five-wire
    Power280KW
    Raw materialWC-Co slurry
    Slurry mediumAlcohol (water≤10%)
    Solid in slurry70%~85%
    Alcohol recycling rate95%
    Output300kg/h
    Gas inlet temperature of drying tower190-230℃
    Gas outlet temperature of drying tower80-100℃
    Alcohol inlet temperature of cleaning tower16-20℃
    Gas outlet temperature of cleaning tower19-25℃
    Oxygen content in drying tower3%
    N2 supply

    3-4bar (tower)

    Purity: 99.9%

    N2 consumption

    60Nm3/h (O2 exhausting process)

    7Nm3/h (other process)

    Cooling water13-15℃,2-3 bar
    Compressed air5-6 bar
    Compressed air consumption5m3/h
    Residual alcohol in RTP0.2-0.3%
    Powder temperature25
    Material recycling rate

    98%

    94% (Drying tower);

    4% (Dust collecting system)

    3.Features

    Spray Drying Tower is mainly composed of mixture inlet system, heating system, drying tower, dust collecting system, cleaning system, condensation system, gas system, material outlet system and electric control system.
