    EFPE automatic continuous operating Pusher Reduction Furnace

    .jpg

    Product Description

    I. Overview

    The pusher reduction furnace is endowed with excellent furnace tube with prolonged service life. This continuous furnace is highly recommended for reduction of all kinds of metal oxides, calcination of all salts and sintering of powder metallurgies, etc.. Thanks to integrated furnace structure, customers benefit from easy installation and low maintenance.


    II. Technical specifications

    Specification/ ModelEF-RF-200/70-3EF-RF-285/70-5EF-RF-300/70-5EF-RF-400/80-5
    Rated heating temperature (°C)1050°C
    Quantity of furnace tube1222
    Size of furnace tube in heating zone (mm) (W x H x L)220x70x3700310x70x7000320x70x7200420x80x7500
    Quantity of heating zone3555
    Gas consumption (Nm3/h)5101020
    Production capacity (kg/h)30~6060~9090~150130~170
    Rated heating power (kW)70100120135
    Rated supply voltage (V)380V50 Hz
    Material of muffle furnace tube1Cr18Ni9Ti(SU321), OCr25Ni20(SUS310S)
    Material of heating elementsHigh-temperature resistance wire, silicon carbide rod
    Furnace structureRegular pattern and whole fiber lining structure
    Boat pushing methodElectric, pneumatic and hydraulic
    Temperature controlling methodPID+SCR
    Overall size (roughly) (mm) (W x H x L)1450x1600x115001850x1650x173002050x1700x175002150x1750x18000

    III. Features

    1. This powder metallurgy furnace comes with resistance heating or fuel heating.

    2. There are single tube, double tube and multiple tube reduction furnaces for selection.

    3. Compact structure is responsible for promoted thermal insulation property and reduced maintenance workload.

    4. Automatic temperature control offers ease of operation.


    Company Information

    Easyfashion Industry is a comprehensive product supplier with many joint ventures and cooperative enterprises, specializing in designing, manufacturing, and selling various kinds of industrial furnaces,such as heat treatment machines , material heat treatment machines and so on. Our company has many advanced powder and metallurgy products manufacturing and melting technology, specially with abundant technical foundations and production experiences of smelting and advanced material production equipments.
