Intergrated Vacuum Degreasing and Sintering Furnace

    Buy cheap Intergrated Vacuum Degreasing and Sintering Furnace from wholesalers

    Buy cheap Intergrated Vacuum Degreasing and Sintering Furnace from wholesalers
    • Buy cheap Intergrated Vacuum Degreasing and Sintering Furnace from wholesalers

    Intergrated Vacuum Degreasing and Sintering Furnace

    Ask Lasest Price
    Brand Name : EasyFashion
    Model Number : GN5518A
    Certification : ISO9001:2008
    Price : To be discussed
    Payment Terms : T/T, Western Union
    Supply Ability : 15~25 sets per year
    Delivery Time : 90~160 days
    • Product Details
    • Company Profile

    Intergrated Vacuum Degreasing and Sintering Furnace

    Integrated Vacuum Degreasing and Sintering Furnace


    Integrated Vacuum Degreasing and Sintering Furnace integrate the functions of de-waxing, sintering, atmosphere controlling and cooling etc.



    Model

    GN5518A

    GN3312A


    Rated voltage


    380 V 50 Hz, three-phase five-wire


    Dimension of furnace

    4500×5400×3500 mm

    4500×4250×3500 mm


    Dimension of usable space

    500×500×1800 mm

    300×300×1200mm


    Max. load weight

    1500 kg

    500 kg


    Weight of furnace

    ≈5500 kg

    ≈4000 kg

    Stand area

    ≈5200×6000 mm

    ≈4500×4000mm


    Power

    340 kVA

    200 kVA


    Max. testing temperature

    1600°C


    Max. working temperature

    ≤1550°C


    Temperature control method


    3 zones


    Temperature uniformity

    ≤±7°C

    (Ceramic ring)


    Hc deviation

    ±0.3KA/M


    Com deviation

    ≤±0.2%


    Temperature increasing rate (without loading)

    15°C/min(≤1000);

    10°C/min(≥1000)


    Ultimate vacuum


    ≤2Pa, tested in cold and clean chamber


    Vacuum Leak rate


    ≤2Pa/h(24 hours average), tested in cold and clean chamber


    Pumping speed

    (in cold and clean chamber)


    ≤20 min., pumping from 1.13×105Pa to 5Pa


    Wax collecting rate

    ≥98%


    Cooling speed

    (without loading)


    (cooling water ≤30°C)


    From working temp. to 800°C, ≤ 3 h


    From 800°C to opening door, ≤ 6 h


    From working temp. to 800°C, ≤ 2 h


    From 800°C to opening door, ≤ 5 h
