    Vacuum Heat Treatment Metal Sintering Furnace For Alloy Steel

    Ask Lasest Price
    Brand Name : Easyfashion Industry
    Model Number : EF-VGQ-9912
    Certification : CE Certificate
    Price : 50000
    Payment Terms : T/T, D/A, D/P, Western Union
    Supply Ability : 50 sets per year
    Delivery Time : max. 120 days
    • Product Details
    • Company Profile

    Vacuum Heat Treatment Metal Sintering Furnace For Alloy Steel

    Vacuum Heat Treatment High Vacuum Furnace Metal Sintering Furnace


    1. Overview:

    This furnace is mainly used for vacuum quenching of tool steel and alloy steel, and vacuum tempering and vacuum annealing of other materials, etc..


    2. Specifications:

    ItemsDetails
    Applicable processing products

    stainless steel based alloys, hard alloys, high temperature alloy, etc.

    temperature alloy, etc.


    Rated heating power

    260KW (The actual power is adjustable, subject to the final design)


    Power supply voltage380V 50Hz
    Heating zonethree zones
    Temperature controlling methodPID
    Max. working temperature1400°C
    Common working temperature≤1320°C
    Working zone size900*900*1200mm(W*H*L)
    Heating materialgraphite
    Cooling methodaxial flow fan pressure cooling or water cooling in furnace (centralized water supply & drainage)
    Ultimate vacuum degree of unloaded furnace in cold state10-4mbar
    Pressure rising rate≤0.67Pa/h
    Rated pressure of pneumatic valve gas source0.6-0.8MPa
    Furnace temperature uniformity±5°C
    Gas pressure≤8bar
    Gas pressure constant sinteringadjustable
    Cooling water pressure0.1-0.3Mpa


    3. Basic Configuratio

    • The furnace is mainly composed of vacuum furnace body, heating chamber, vacuum system, inflation system, fast cooling system, water cooling system, electrical control system, charging forklift system, etc..

    4. Documents in the delivery

    • NO.Documents ListQty.
      1Operation manual of EF-VGQ-99121 copy
      2Qualification certificate of EF-VGQ-99121 copy
      3Operation manual of temperature controller2 copies
      4Operation manual of voltage regulator2 copies
      5Maintenance instruction of EF-VGQ-99121 copy
      6Furnace general size diagram1 copy
      7Electric control cabinet circuit diagram1 copy
      8Working diagram of wearing part1 copy
    5. FAQ

    1. How can I know your factory can produce equipment I need?

    Re: Contact us and let us know your requirements of equipment. Then we will send these requirements to our technical department. So we will know whether our factory can offer you equipment or not.


    2. Does your company customize equipment for customer?

    Re: Yes, we can customize equipment according to customers' requirements.


    4. How can I believe your quality?

    Our equipment are eqquiped with mechanical parts of world renowned brands like Schneider, Omron and so on, and also approved ISO9001 certification.
